50L Vacuum Mixer Equipment
Vacuum Emulsifying MixerPRODUCT PARAMETERS
|
Model |
Capacity(L) |
Mixing |
Homogenizing |
||
|
Power（kw） |
Speed(r/min） |
Power（kw） |
Speed(r/min） |
||
|
WJ-M50 |
50 |
0.55 |
0-60 |
1.5 |
0-3000 |
|
WJ-M100 |
100 |
0.75 |
0-60 |
1.5 |
0-3000 |
|
WJ-M200 |
200 |
1.5 |
0-60 |
3 |
0-3000 |
|
WJ-M300 |
300 |
2.2 |
0-60 |
4 |
0-3000 |
|
WJ-M500 |
500 |
2.2 |
0-60 |
5.5 |
0-3000 |
|
WJ-M1000 |
1000 |
4 |
0-60 |
11 |
0-3000 |
|
WJ-M2000 |
2000 |
5.5 |
0-60 |
15 |
0-3000 |
Working Principle
The 50L Vacuum Homogenization Emulsifier Mixer is mainly composed of a pretreatment pot, an emulsification stirring pot, a lifting system, a vacuum system, an electrical control system and other parts. Its working principle is as follows:
After the materials are heated and stirred and mixed in the water and oil pans, they are sucked into the emulsification pot by a vacuum pump. In the emulsification pot, the materials are always stirred against the pot shape by the stirring paddle and polytetrafluoroethylene scraper in the homogenization pot, sweeping away the wall-hanging sticky materials, so that the scraped materials continuously generate new interfaces. After a series of processes such as shearing, compression, and folding by the stirring blade, the materials are quickly broken into particles of 200μm to 2μm. Since the emulsification pot is in a vacuum state, the bubbles generated by the materials during the stirring process are extracted in time, thereby obtaining a bubble-free, delicate and stable product.
After the materials are heated and stirred and mixed in the water and oil pans, they are sucked into the emulsification pot by a vacuum pump. In the emulsification pot, the materials are always stirred against the pot shape by the stirring paddle and polytetrafluoroethylene scraper in the homogenization pot, sweeping away the wall-hanging sticky materials, so that the scraped materials continuously generate new interfaces. After a series of processes such as shearing, compression, and folding by the stirring blade, the materials are quickly broken into particles of 200μm to 2μm. Since the emulsification pot is in a vacuum state, the bubbles generated by the materials during the stirring process are extracted in time, thereby obtaining a bubble-free, delicate and stable product.
Product FAQ
Q: Is the operation difficult?
A: No. It has an intelligent control system with a simple interface. After brief training, operators can handle it easily.
Q: Is maintenance troublesome?
A: No. Just clean and check key parts regularly. Such as stirrer and seals. Low cost and short time-consuming.
Q: Does it ensure stable product quality?
A: Yes. Vacuum homogenization avoids bubbles. Precise control of parameters ensures consistent quality.
Q: How about its capacity?
A: 50L capacity is suitable for medium-scale production. Can meet the needs of different industries.
Q: Is it energy-efficient?
A: Yes. Optimized design reduces energy consumption. While ensuring high-performance operation.
A: No. It has an intelligent control system with a simple interface. After brief training, operators can handle it easily.
Q: Is maintenance troublesome?
A: No. Just clean and check key parts regularly. Such as stirrer and seals. Low cost and short time-consuming.
Q: Does it ensure stable product quality?
A: Yes. Vacuum homogenization avoids bubbles. Precise control of parameters ensures consistent quality.
Q: How about its capacity?
A: 50L capacity is suitable for medium-scale production. Can meet the needs of different industries.
Q: Is it energy-efficient?
A: Yes. Optimized design reduces energy consumption. While ensuring high-performance operation.
