High Shear Mixing Disperser Mixer
Mixing Tank With AgitatorPRODUCT PARAMETERS
|
Model |
Capacity(L) |
Mixing |
Homogenizing |
||
|
Power（kw） |
Speed(r/min） |
Power（kw） |
Speed(r/min） |
||
|
WJ-M50 |
50 |
0.55 |
0-60 |
1.5 |
0-3000 |
|
WJ-M100 |
100 |
0.75 |
0-60 |
1.5 |
0-3000 |
|
WJ-M200 |
200 |
1.5 |
0-60 |
3 |
0-3000 |
|
WJ-M300 |
300 |
2.2 |
0-60 |
4 |
0-3000 |
|
WJ-M500 |
500 |
2.2 |
0-60 |
5.5 |
0-3000 |
|
WJ-M1000 |
1000 |
4 |
0-60 |
11 |
0-3000 |
|
WJ-M2000 |
2000 |
5.5 |
0-60 |
15 |
0-3000 |
|
WJ-M3000 |
3000 |
7.5 |
0-50 |
18.5 |
0-3000 |
|
WJ-M5000 |
5000 |
11 |
0-50 |
22 |
0-3000 |
1. Excellent mixing performance: It can thoroughly blend materials with diverse properties, making the material composition more consistent and enhancing the product quality.
2. Remarkable homogenization impact: It can break large particles within the material into smaller ones, enhance the stability and uniformity of the material, and decrease the occurrence of product stratification and precipitation.
2. Remarkable homogenization impact: It can break large particles within the material into smaller ones, enhance the stability and uniformity of the material, and decrease the occurrence of product stratification and precipitation.
3. User - friendly operation: The control system is straightforward and comprehensible, with convenient operation. It enables automated production and boosts production efficiency.
4. Cleaning - friendly: The structural design of the pot body and the mixing device is rational, easy to clean and maintain, and complies with hygiene standards.
4. Cleaning - friendly: The structural design of the pot body and the mixing device is rational, easy to clean and maintain, and complies with hygiene standards.
Structural Composition
1. Pot body: Usually made of stainless steel or other materials, it has good corrosion resistance and thermal conductivity. The pot body has a single-layer, double-layer, or multi-layer structure, which can achieve jacket heating or cooling functions to meet different process requirements. For example, in the production of cosmetics, precise temperature control of materials is required, and a double-layer pot structure can effectively achieve this.
2. Mixing device: This is the core component of a homogeneous mixing pot, generally consisting of a mixing shaft, mixing blades, and a driving motor. The shape and size of the mixing blade are designed according to different materials and mixing purposes, commonly including anchor type, paddle type, turbine type, etc. The driving motor provides power, allowing the stirring blades to rotate at high speed, achieving mixing and blending of materials.
3. Homogenization device: used for homogenizing materials to make the particles in the material finer and more uniform. Homogenization devices are usually composed of homogenization heads or homogenization pumps, which use high-speed rotation or high-pressure action to crush large particles in the material into small particles, improving the stability and uniformity of the material.
4. Heating and cooling system: According to the needs of the production process, the homogenization mixing pot can be equipped with heating and cooling systems. Heating methods include electric heating, steam heating, thermal oil heating, etc; The cooling method is usually achieved through the circulation of cooling water in the jacket.
5. Control system: including temperature control, mixing speed control, time control and other functions, can accurately control the operating parameters of the homogeneous mixing pot, ensuring the stability and reliability of the production process.
Product Applications
Homogeneous mixing tank can be used in the cosmetics industry to produce products such as shampoo, making the texture uniform and delicate; Used in the food industry for the production of sauces and other products to improve taste quality; Preparing drug formulations in the pharmaceutical industry to improve the stability of therapeutic efficacy; Producing coatings and other materials in the chemical industry to improve product performance and quality.
